EPS Thermocol Foam Ball Making Machine

Looking for high-quality EPS Thermocol Foam Ball Making Machine? We are a reputable factory dedicated to producing top-notch foam ball making machines.
Request a Quote

PRODUCTS DETAILS

  • Overview
  • Features
  • Technical Data
  • FAQ
Overview

Basic Info.

Model NO.
ESPB50/110/150
Computerized
Computerized
Certification
CE
Transport Package
Container
Specification
ESPB-50/90/130/160
Trademark
EPSOLE
Origin
China
Production Capacity
150 Set / Year

Product Description

EPS Thermocol Foam Ball Making Machine



EPS Thermocol Foam Ball Making Machine
EPS Thermocol Foam Ball Making Machine

EPS Thermocol Foam Ball Making Machine

EPS Production Technology - Pre Foaming:

Batch foaming After weighing the EPS beads in batches, they enter the pre foaming machine for pre foaming. -High precision of pre foaming -Wide range of foaming density -EPS raw materials with low pentane content can be prepared -Generally, EPS raw materials contain 6-7% pentane -EPS raw materials with low pentane content contain 3-4.5% pentane (pre released in a pressurized pre foaming machine)
Methods of adjusting foaming density -by adjusting the quantity of raw materials to be put in each time -by adjusting the heating time of steam -by adjusting the height of EPS beads in the foaming machine (at which point the steam is cut off) -by adjusting the steam pressure -by regulating the supply of steam (steam to air ratio) Control mode of batch foaming -Control steam pressure (0.1 to 0.6 bar) - low density -Control steam temperature (85 to 99 ° C) - high density -Air mixing - high density

Features

Including common dry bed,auto-feeder,screening and auto-weighing device.
Steam system: controlled by relief valve and angle valve
Filling system: adopt electronic weighing system,set on touch screen and the equipment is available for weighing automatically
Material level control: controlled by photo sensor
Electric control: with PLC&touch screen

Technical Data

ITEM Type
  ESPB-50 ESPB-110 ESPB-150 ESPB-160
Expansion  Container Diameter 500mm 1100mm 1500mm 1600mm
Volume 0.14m3 1.4m3 4.5m3 5.4m3
Useable Volume 0.1m3 0.9m3 3.2m3 4.5m3
Steam Entry DN25 DN50 DN50 DN100
Consumption 0.5-0.7kg/cycle 8-11kg/cycle 15-18kg/cycle 18-20kg/cycle
Pressure 0.6-0.8Mpa 0.6-0.8Mpa 0.6-0.8Mpa 0.6-0.8Mpa
Compressed Air Entry DN20 DN25 DN40 DN40
Consumption 0.2-0.3m3/cycle 0.5-0.6m3/cycle 0.5-0.6m3/cycle 0.5-0.8m3/cycle
Pressure 0.6-0.8Mpa 0.6-0.8Mpa 0.6-0.8Mpa 0.6-0.8Mpa
Drainage Drainage Port DN80 DN80 DN100 DN150
Condensate DN20 DN80 DN40 DN50
Productive Capacity   12g/l
18g/l
25g/l
32g/l
70kg/h
100kg/h
110kg/h
130kg/h
12g/l
15g/l
20g/l
30g/l
240kg/h
320kg/h
430kg/h
600kg/h
12g/l
15g/l
20g/l
30g/l
600kg/h
900kg/h
1200kg/h
1500kg/h
12g/l
15g/l
18g/l
25g/l
1400kg/h
1800kg/h
2300kg/h
2800kg/h
Second expansion
8g/l
10g/l
800kg/h
1000kg/h
MaterialConveying Line   150mm 150mm 250mm 250mm
Power   9.5kw 16.1kw 25.85kw 3.5kw
Density   12-140g/l 12-30g/l 12-30g/l 12-30g/l
Toleranoe   ≤±2% ≤±2% ≤±5% ≤±5%
Overall Dimension (L×W×H) 3000×3800×3800(mm) 5600×3800×4530(mm) 6500×4150×5400(mm) 8600×3500×5800(mm)
Weight   1500kg 3500kg 5000kg 8000kg
Room Height Required   5000mm 5000mm 6000mm 7000mm
EPS Thermocol Foam Ball Making Machine

EPS Thermocol Foam Ball Making Machine EPS Thermocol Foam Ball Making Machine

EPS Thermocol Foam Ball Making Machine


EPS Thermocol Foam Ball Making Machine

FAQ


1. Q: Where is your company located? How can I visit there?
A: Our factory is located in Hangzhou City, Zhejiang Province, China. Welcome to visit us.

2. Q. Do you have some videos where we can see the line producing?
A: Yes, we can provide some videos for reference.

3. Q: What's the MOQ?
A: Our MOQ is 1 Set.

4. Q: Can I have my own customized product?
A: Yes. Your customized requirements for color, logo, design, package, carton mark, your language manual etc. are very welcome.

5. Q: Can you produce according to the samples?
A: Yes, we can produce mold by your samples or technical drawings.

6. Q: What's the delivery time?
A: Generally, it will take 20 to 60 days after receiving your advance payment. The specific delivery time depends on the items and
the quantity of your order.

7. Q: What is the payment terms?
A: T/T, L/C, D/P at sight

8. Q: How does your factory carry out quality control?
A: We attach great importance to quality control.Every part of our products has its own QC.

9. Q: What certificate do you have?
A: We have TUV, CCC, CE (EN71, EN14765), SGS, ISO9001 etc. Also we can apply any certificate if you need if the qty is OK.
