EPE Foam Board Horizontal and Vertical EPE Foam Cutting and Slitting Machine

Introducing our EPE Foam Board Horizontal and Vertical EPE Foam Cutting and Slitting Machine. We are a factory providing high-quality foam cutting solutions.
Request a Quote

PRODUCTS DETAILS

Basic Info.

Suitable Substrates
Pep,Foam
Packaging Material
Wood
Transport Package
Professional Export Packaging
Origin
China
HS Code
9031809090
Production Capacity
100/Year

Product Description

EPE foam board horizontal and vertical EPE foam cutting and slitting machine

Features of EVA slitting machine:
1. EVA slitting machine programmable control system, servo motor automatic feeding, with multi-knife, multi-size, simultaneous transverse and vertical cutting;
2. EVA slitting machine can adjust the height of the pressure roller electrically, the height is digitally displayed, and the slitting speed can be adjusted;
3..EVA slitting machine uses three-phase 380V power supply;
4.. The EVA slitting machine is easy to adjust the slitting size, which is convenient for production diversification.
5. The roller is used to drive the material up and down to make the material feeding and discharging automatic and fast;
6. The machine has automatic trimming function and automatic cutting head, which can automatically trim some cotton with uneven edges;
7. Using servo motor and servo system to control the feeding size and length, the size is accurate and the error is extremely small;
8. The cross-cutting adopts a circular knife to cut the material, and the cross-cutting guide rail is a linear guide rail;
9. The operation of the full CNC system is simple and convenient.
9. Touch screen operation, simple and convenient to operate.
10. Safety performance: The machine is equipped with an infrared grating sensor switch, the machine automatically stops when it is close to the dangerous area, and automatically returns to normal after leaving the dangerous area;
11. Automatic output counting function, convenient and quick;

EVA slitting machine product parameter configuration:
1. The effective cutting width of the machine: 1650mm, the effective cutting thickness of EVA: 2mm-60mm;
2. Scope of application of the machine: suitable for cutting EVA, high foaming EPE;
3. Servo system: Feeding motor: Weide 3.8KW servo motor, 2500S/min, torque: 15N;
4. Vertical cutting circular knife motor: 3.7KW, 1:7.5 geared motor;
5. Lifting motor: 200W, 1:30 geared motor;
6. Cross-cutting circular knife motor 1.5KW 1:10 geared motor
7. Cross-cutting motor: 35N stepper motor;
8.2 Shangwin 30*30*1960mm linear guide rail;
9. Roller diameter: 6*95mm; Dimensional accuracy: 5/1000
10. Randomly distribute 10 circular knives and 1 cross-cut circular knives;
11. Machine net weight: 1200KG;
EPE Foam Board Horizontal and Vertical EPE Foam Cutting and Slitting MachineEPE Foam Board Horizontal and Vertical EPE Foam Cutting and Slitting Machine
EPE Foam Board Horizontal and Vertical EPE Foam Cutting and Slitting MachineEPE Foam Board Horizontal and Vertical EPE Foam Cutting and Slitting MachineEPE Foam Board Horizontal and Vertical EPE Foam Cutting and Slitting MachineEPE Foam Board Horizontal and Vertical EPE Foam Cutting and Slitting Machine


EPE Foam Board Horizontal and Vertical EPE Foam Cutting and Slitting Machine
EPE Foam Board Horizontal and Vertical EPE Foam Cutting and Slitting MachineEPE Foam Board Horizontal and Vertical EPE Foam Cutting and Slitting Machine
Our service:
During the whole business process, we offer Consultative Selling service.
1)Customer inquiry process:
Discussing testing requirements and technical details, suggested suitable products to customer to confirm.
Then quote the most suitable price according to customer requirements.

2)Specifications customize process:
Drawing related drawings to confirm with customer for customized requirements. Offer reference photos to show the appearance of the product. Then, confirm the final solution and confirm the final price with the customer.

3)Production and delivery process:
We will produce the machines according to confirmed PO requirements. Offering photos to show the production process.
After finishing production, offer photos to the customer to confirm again with the machine. Then do own factory calibration or third party calibration(as customer requirements). Check and test all the details and then arrange packing.
Deliver the products is confirmed shipping time and inform the customer.

4)Installation and after-sale service:
Defines installing those products in the field and providing after-sales support.

FAQ:
1. Are you a Manufacturer? Do you offer after-sales service? How can I ask for that? And how about the warranty?
     Yes, we are the one of professional Manufacturers like Environmental Chambers, Leather shoe testing equipment, Plastic Rubber testing Equipment... in China. Every machine purchased from our factory has 12 months warranty after shipment. Generally, we offer 12 months for FREE maintenance. while considering sea transportation, we can extend 2 months for our customers.
      Moreover, If your machine doesn't work, you can send us an e-mail or call us we will try our best to find the problem through our conversation or by video chat if necessary. Once we have confirmed the problem, the solution will be offered within 24 to 48 hours.
 2. What about the delivery term?
 For our standard machine which means normal machines, If we have stock in the warehouse, is 3-7 working days;
 If there is no stock, normally, the delivery time is 15-20 working days after payment received;
 If you are in urgent need, we will make a special arrangement for you.
 3. Do you accept customization services? Can I have my logo on the machine?
Yes, of course. We can not only offer standard machines but also customized machines according to your requirements. And we can also put your logo on the machine which means we offer OEM and ODM service.
4. How can I install and use the machine?
Once you have ordered the testing machines from us, we will send you the operation manual or video in English version through Email.
Most of our machine is shipped with a whole part, which means it is already installed, you just need to connect the power cable and start to use it. And if it's necessary, we can also assist you to install your machine on site.
