CNC Graphite Gasket Non-Asbestos Asbestos Gasket PTFE Rubber Motorcycle Gaskets Plastic Polyurethane Sealing Ring Gasket Automatic Knife Cutter Cutting Machine

CNC Graphite Gasket Non-Asbestos Asbestos Gasket PTFE Rubber Motorcycle Gaskets Plastic Polyurethane Sealing Ring Gasket Automatic Knife Cutter Cutting Machine - Factory direct gasket manufacturing for a wide range of applications. Custom solutions available.
Request a Quote

PRODUCTS DETAILS

  • Overview
  • Product Parameters
  • After Sales Service
  • FAQ
Overview

Basic Info.

Model NO.
YC-0906L
Application
Paper, Plastic, Leather, Fabric, Gasket
Power Source
Electric
Layout
Horizontal
Name
Digital Cutting Machine
Model
Yc-0906L
Max. Cutting Speed
1200mm/S
No-Load Speed
1500mm/S
Multifunctional Head Cutting Tools
Oscillating Knife,Driven Rotary Cuttting Tool
Cutting Thickness
0.1-20mm
Cutting Accuracy
0.1mm
Transmission Interface
Ethernet
Motor
Panasonic Servo Motor
Transmission System
Smtycc Linear Rail and Rack
Fixed Mode
Vacuum Absorb
Rated Power
11kw or Others
Operation Properties
Online
Safety Device
Infrared Blocking Device,etc
Cutting Materials
Fabric, Leather, PVC and Other Flexible Materials
Transport Package
Wooden Cases.
Specification
900*600mm
Trademark
YUCHON
Origin
Shandong Jinan
Production Capacity
100 Sets/Month

Product Description

Yuchon Machine Advantages:
1. Equipped with Yuchen intelligent cutting head, the cutter can be changed according to the need, all kinds of gaskets can be effectively cut, and the practicability is strong.
2. Equipped with automatic feeding device, which can realize continuous feeding, large-span cutting, unlimited theoretical cutting length, improve production efficiency, and high degree of automation.
3. Yuchen CNC machine tools have high cutting accuracy and small errors.
4. Vibrating knife cutting, the cutting surface is smooth and round, without secondary processing, can be used directly, reducing production procedures and improving production efficiency.


Brand:  Yuchon
Model:  YC-0906L(size can be customized)
Work Size:  900*600mm
Applicable cutting materials:  asbestos gasket, graphite gasket, rubber gasket, etc
cutting tool:  Pneumatic knife , Oscillating knife


CNC Graphite Gasket Non-Asbestos Asbestos Gasket PTFE Rubber Motorcycle Gaskets Plastic Polyurethane Sealing Ring Gasket Automatic Knife Cutter Cutting Machine
CNC Graphite Gasket Non-Asbestos Asbestos Gasket PTFE Rubber Motorcycle Gaskets Plastic Polyurethane Sealing Ring Gasket Automatic Knife Cutter Cutting Machine

CNC Graphite Gasket Non-Asbestos Asbestos Gasket PTFE Rubber Motorcycle Gaskets Plastic Polyurethane Sealing Ring Gasket Automatic Knife Cutter Cutting Machine

Product Parameters
Model YC-1625L
YC-1625A
YC-1630L
YC-1630A
YC-1830L
YC-1830A
Other sizes are customizable
Working area 2500×1600mm 3000×1600mm 3000×1800mm
Operation properties Online / offline operation; continuous cutting with high efficiency, 7*24 with zero downtime
Safety device Infrared blocking device,Emergency stop button switch, Intelligent anti-collision device.
sensitive response; safe and reliable
Max. cutting speed 1200mm/s
No-load speed 1500mm/s
Multifunctional head cutting tools Oscillating knife cutting tool, Driven rotary cutting tool,Pneumatic cutting tool, Milling tool, Kiss cutting tool,V-cutting tool, Creasing wheel, Punching tool, Drawing pen etc.
Cutting thickness 0.1-20mm ; 0.1-60mm0.1-20mm (subject to material) ; 0.1-60mm(Optional)
Cutting accuracy ±0.1mm
Transmission interface Ethernet
Transmission system Panasonic Servo Motor/SMTYCC Linear rail and rack
Fixed mode Vacuum absorb
Supply voltage AC 220V 380V±10%,50HZ
Rated power 11KW or others

CNC Graphite Gasket Non-Asbestos Asbestos Gasket PTFE Rubber Motorcycle Gaskets Plastic Polyurethane Sealing Ring Gasket Automatic Knife Cutter Cutting Machine

CNC Graphite Gasket Non-Asbestos Asbestos Gasket PTFE Rubber Motorcycle Gaskets Plastic Polyurethane Sealing Ring Gasket Automatic Knife Cutter Cutting Machine


CNC Graphite Gasket Non-Asbestos Asbestos Gasket PTFE Rubber Motorcycle Gaskets Plastic Polyurethane Sealing Ring Gasket Automatic Knife Cutter Cutting Machine
CNC Graphite Gasket Non-Asbestos Asbestos Gasket PTFE Rubber Motorcycle Gaskets Plastic Polyurethane Sealing Ring Gasket Automatic Knife Cutter Cutting Machine

After Sales Service

CNC Graphite Gasket Non-Asbestos Asbestos Gasket PTFE Rubber Motorcycle Gaskets Plastic Polyurethane Sealing Ring Gasket Automatic Knife Cutter Cutting Machine
CNC Graphite Gasket Non-Asbestos Asbestos Gasket PTFE Rubber Motorcycle Gaskets Plastic Polyurethane Sealing Ring Gasket Automatic Knife Cutter Cutting Machine
CNC Graphite Gasket Non-Asbestos Asbestos Gasket PTFE Rubber Motorcycle Gaskets Plastic Polyurethane Sealing Ring Gasket Automatic Knife Cutter Cutting Machine
CNC Graphite Gasket Non-Asbestos Asbestos Gasket PTFE Rubber Motorcycle Gaskets Plastic Polyurethane Sealing Ring Gasket Automatic Knife Cutter Cutting Machine

FAQ

1.payment terms:
L/C,Western Union,T/T,Paypal
2.Delivery time:
Standard machine:7-15 days
Customized machine:10-25 days
3.Packing:
plastic film inside and plywood case for outside packing
4.Transportation fee
Ship by sea or airplane, railway. Actual cost reimbursement
5.instal
We offer video teaching,and we have professional technicians who will help you to install, guide and train
6.After sales service
1).3 year free warranty
2).Life time free maintenance service.
3).24 hours online service, free technical support with different languages.
4).Door to door technical support when needed
